Porkolator Distortion


Buzzy, fuzzy, and totally badass. Back in the 1970s, Interfax, a small effect company in Milwaukee, Wisconsin, created the Harmonic Percolator. It was a weird distortion pedal whose enclosure had all the visual charm of a 1987 PC. (Think beige.) No one gave a crap, and the Percolator soon vanished.

That is, until Chicago guitarist/engineer Steve Albini rediscovered it years later. It became his secret weapon. Eventually the Percolator became a popular DIY project, and several manufacturers have created near-exact clones.

But Porkolator isn’t one of those. Yeah, it swipes some ideas from the original circuit, but it sharpens the core tone and vastly expands the range.

Totally not tubular. The Percolator’s distortion was edgy and aggressive. Some describe it tone as “tube-like,” but they must be deaf — it sounds nothing like tube distortion. When tubes get hot, note attacks get softer and high frequencies get rounded off. But on the Percolator, note attack remains crisp and defined, even at high gain. It sounds more like overdriving the input of a funky tape recorder. The tones also have sharp resonant peaks, perfect for cutting through onstage or in a mix. Because the pedal emphasizes a guitar’s particular resonant peaks, the Porkolator’s color varies from instrument to instrument.

The two-transistor circuit is bizarre: It’s got one negative-ground silicon transistor and one positive-ground germanium transistor. I kept that basic architecture, but took it in new directions. (I even auditioned the rare transistors used in the originals, but these alternatives sound way better.)

Perk vs. Pork.The original had a single gain control and a passive master volume. It wasn’t particularly loud. Here, though, there are two gain stages, one at the input and one mid-circuit. They’re highly interactive, and they’re fastidiously scaled to yield great tones throughout the entire ranges of their knobs. The IN knob sets your input capacitance — think of it as a “fat vs. crisp control.” GAIN slathers on the distortion. OUT is a master volume control.

Porkolator can get loud as fuck. Instead of a passive volume control, there’s a JFET-driven gain stage. At low settings, you can duplicate the original output, but with airier highs and clearer low-mids. When you crank it, you get Götterdammerung. But you can also get tough tones at modest levels.

Despite all its gain, Porkolator has extraordinary dynamic response. If you’re the sort of guitarist who uses your volume control to get varying shades of distortion, you’ll be in hog heaven.

Porkolator runs on standard 9-volt batteries or power supplies. It was created in San Francisco by me and is built in Michigan by skilled craftspeople paid a fair wage. It comes with a lifetime warranty.

TO USE: Think of IN and GAIN as separate but interactive distortion controls. With IN set high and GAIN set low, you get fat, bottom-heavy sounds. With IN low and GAIN high, there’s crisper attack and leaner lows. Explore — there are many cool combinations. You can get many more shades by adjusting your guitar’s volume control. Set your final level with OUT.

BACKGROUND INFO FOR PEDAL GEEKS. Here’s an article and a video that I made a few years ago on Harmonic Percolators. It includes a clone made with the exact parts as the original, including the rare transistors, so you can hear what the vintage version was all about. The video’s final pedal is an early version of Porkolator. It’s changed a great deal since then, so don’t consider this a demo. (It’s gotten louder, heavier and meaner.) This is just some fascinating stompbox history!
